Classic Car LEDs Ltd



Regular price £87.90 GBP
Regular price Sale price £87.90 GBP
Sale Sold out
Kit Required

H4 7 inch light units supplied with our top range H4 LED upgrade available in cold modern white or classic warm white. This upgrade will dramatically improve the lighting performance of your headlights compared to your older style sealed beam units and considerably reduce the current drawn.

The reflectors are supplied with no pilot light and available for Right Hand Drive and Left hand drive Vehicles - please ensure you select the correct option. Reflectors are high quality aftermarket as Lucas have stopped making these now.

These are available as a single unit upgrades for motorcycles etc or in pairs for cars and vans. There is a discount for purchasing a pair. Please select the kit and colour required from the drop down menus. In the quantity box, please advise the number of the chosen kits that you wish to purchase.

We offer the H4 LED in 4300k soft warm white, very similar to the colour output of a standard filament bulb. Ideal for classic vehicles to retain a period look but giving you a much brighter light with a greatly reduced load on your electrical system. We're not sure you can get these anywhere else. Alternatively you can choose the 6000k cold modern white. Both have similar light output, the only difference is the colour temperature to give you a classic or modern look as you prefer.

Our new smaller build with a smaller control unit and easier mounting, these are a great upgrade from Halogen Lamps.

IP 65 Waterproof and vibration proof with IC Control, they are manufactured from aviation grade aluminium so are built to last.

The placement of the SMD's has been specifically designed to mimic the dimensions of a standard H4 Halogen bulb. As a result, you can be confident that they will produce an improved brighter light that will not dazzle other road users. In addition the reach of the beam (how far you can see ahead) is excellent and will provide an all round much improved performance over halogen bulbs.

These can be universally fitted with ease and are a simple plug and play solution with no changes to your existing wiring, they plug into your existing H4 socket.

They switch on immediately to give you instant light at maximum brightness. Cooling is provided by the built in high performance fan. They WILL improve your night time driving experience.

These LEDs are not polarity sensitive so will work with negative and positive earth vehicles.

Colour: Pure White 6000-6500K (standard halogen is 3500-4500k) or Warm White 4300k.
Voltage: 9-32V will suit 12 volt and 24 volt vehicles
Lumen: 4500 main beam and 4500 dipped beam per bulb (standard halogen is around 1200 and 700 Lumen respectively)
Lifespan: 50,000 hours
Current Drawn: 3.5 Amps (standard halogen uses 5 Amps) - the power drawn is dramatically reduced

The control unit measures 43 x 27 x 15mm.

Our LEDs are all high quality and made to our own demanding specifications. We believe in fair pricing and are confident you will not get a better price unless you want to compromise on the quality or life of your bulbs.

The MOT rules have been clarified from 06.02.23 to allow the use of LED conversions that pass the beam pattern tests for headlights for Class 3, 4, 5 and 7 vehicles (car, private bus and light commercial vehicle) first used before 1 April 1986 and all class 1 and 2 motorcycles of any age.

All prices shown exclude UK and EU VAT which will be added at checkout together with postage where appropriate.

Generic Part Number: H4SBKIT

View full details

Customer Reviews

Based on 1 review
Stuart Watson
Sealed Beam to H4 Upgrade Kit

Received the Kit very promptly. They were for a 1967 AH Sprite . It was a bit tight to fit the IC unit and Heat Sink into the headlamp bucket but it did fit providing the IC unit was held to be horizontal. The headlights are now much brighter and the warm white lights are consistent with the age of the car. Very pleased with the result.
